Alat laboratorium teknik sipil Berpengalaman dan Profesional
  • Berpengalaman dan Profesional

  • Mekar Rahayu Abadi secara legal formal memang baru terbentuk namun secara personal para pendiri telah memiliki pengalaman dan skill yang profesional dibidang produksi dan supplier peralatan untuk pengujian di lapangan maupun di laboratorium baik produksi lokal maupun produk impor.

Alat laboratorium teknik sipil Fokus Kepada Kualitas dan kepuasan pelanggan
  • Fokus Kepada Kualitas dan kepuasan pelanggan

  • Kami berharap  setiap produk yang kami buat dan supply dengan sentuhan kesungguhan “ hati “ bermuara pada kualitas yang sempurna,tepat fungsi ,tepat jumlah dan tepat waktu.

Alat laboratorium teknik sipil Mekar Rahayu Abadi
  • Mekar Rahayu Abadi

  • Mekar Rahayu Abadi ingin berperan serta dan memberikan kontribusi dalam proses pembangunan Indonesia dengan menghasilkan dan mensuplai produk yang berkualitas sesuai dengan standard International.

TENTANG KAMI

CV.Mekar Rahayu Abadi merupakan perusahaan nasional yang bergerak  di bidang produksi alat-alat uji teknik sipil dan pertambangan baik untuk keperluan di lapangan maupun di laboratorium meliputi alat uji Tanah,Beton,Cement,Batuan,Asphalt.Mining Preparation,Drilling dan bergerak juga di bidang General Supplier.

Produk
  • Alat laboratorium teknik sipil mechanican concrete beam test

    mechanican concrete ..

    ASTM C-78 For determining the flexural strength of concrete beam by using a simple beam with third point loading 50 Kn cap., mechanical jack,proving ring, sample size 15 x 15 x 60 cm, welded steel construction Dimension (l x w x h) : 100 x 40 x 100 cm Gross weight : 110kg
  • Alat laboratorium teknik sipil hammer mill

    hammer mill

  • Alat laboratorium teknik sipil Speedy Moisture Tester

    Speedy Moisture Test ..

  • Alat laboratorium teknik sipil Sample Extruder

    Sample Extruder

    For extruding soil specimen from 68 mm sampling tube, welded steel, screw type, supplied without sampling tube. Dimension (I x w x h) : 125 x 15 x 15 cm Gross Weight : 45 Kg Also required,but not part of this set: Wire Saw Sample Can
  • Alat laboratorium teknik sipil Marshall test set

    Marshall test set

    Compression Machine Steel frame, electric, 220 V-AC, 1 set ½ HP, 1 Phase, speed : 2” per minute Compaction Mold Machined steel, galvanized, 4” dia., 1 set 3” height, with collar and base plate Stability Mold Cast aluminium, split type 4” i.d., 1 set 4” wide Compaction Hammer Machined steel, galvanized, 10 lbs. 1 set Hammer weight, 18” drop heigh Compaction Pedestial Wooden base with steel platen 1 pc Compaction Mold Holder Machined steel, quick clamping system 1 set Extruder Steel frame, hydraulic system 1 set Flow meter Cast aluminium, clamping bolt, 1 set with dial indicator 30 x 0.01 mm Water Bath Stainless steel, water hater, 220 V-AC 1 set Thermostat 3085 C Proving Ring 6000 lbs capacity 1 set Dimension ( I x w x h 67 x 50 x 100 cm Gross weight 200 kg
  • Alat laboratorium teknik sipil Wooden Sieve

    Wooden Sieve

    For determining grain size distribution of soil particles or sand/gravel. Brass frame 8” dia. Type Part Name Spesification Sieve 4” Mesh 101.6 mm opening Sieve 3 ½” Mesh 88.9 mm opening Sieve 3” Mesh 76.2 mm opening Sieve 2 ½ “ Mesh 62.5 mm opening Sieve 2” Mesh 50.8 mm opening Sieve 1 ¾ “ Mesh 44.4 mm opening Sieve 1 ½ “ Mesh 38.1 mm opening Sieve 1 ¼” Mesh 31.7 mm opening Sieve 1” Mesh 25.4 mm opening Sieve 7/8” Mesh 22.2 mm opening Sieve 3/4” Mesh 19.0 mm 0pening Sieve 5/8 “ Mesh 15.8 mm opening Sieve 1/2" Mesh 12.7 mm opening Sieve 7/16 “ Mesh11.1 mm opening Sieve 3/8 “ Mesh 9.5 mm opening Sieve 5/16 “ Mesh 7.9 mm opening Sieve 1/4” Mesh 6.3 mm opening Sieve # 4 Mesh 4.75 mm opening Sieve # 8 Mesh 2.36 mm opening Sieve # 10 Mesh 2.00 mm opening Sieve # 12 Mesh 1.70 mm opening Sieve # 16 Mesh 1.18 mm opening Sieve # 20 Mesh 0.850 mm opening Dimension ( l x w x h ) : 22 x 22 x 6.5 cm Sieve # 30 Mesh 0.600 mm opening Gross Weight : 0.75 kg Sieve # 40 Mesh 0.425 mm opening Sieve # 50 Mesh 0.300 mm opening Sieve # 60 Mesh 0.250 mm opening Sieve # 70 Mesh 0.212 mm opening Sieve # 80 Mesh 0.180 mm opening Sieve # 100 Mesh 0.150 mm opening Sieve # 120 Mesh 0.125 mm opening Sieve # 140 Mesh 0.106 mm opening Sieve # 170 Mesh 0.090 mm opening Sieve # 200 Mesh 0.075 mm opening
  • Alat laboratorium teknik sipil Softening point test set

    Softening point test ..

    TASTM D-36 AASHTO T-53 For determining softening point of asphalt and tar using the ring and ball method Type Parts Name Specifications Qty Shouldered Ring Assembly Machined brass, height adjustment 1 Set Standard Ball Steel Ball, 9.52 mm dia. 2 Pc Flash Support Mesh wire gauze variable height adjustment 1 Set Support Assembly Metal,provided with thermometer holder 1 Set Bunsen Buner Heat Resurces 1 Pc Asbestos Wire Gauze 15 cm x 15 cm 1 Pc Beaker Glass 1000 ml capacity 1 Pc Thermometer ASTM 150c, 2 to 860c 1 Pc Dimension (l x w x h): 90 x 30 x 30 cm Gross weight: 10kg Also Requid, but not part of this set: Ladle Butane Field Heater Mixing Bow Stop Watch Spatula
  • Alat laboratorium teknik sipil hydraulic concrete beam testing machine

    hydraulic concrete b ..

    ASTM C-78 For determining the flexural strength of concrete beam by using a simple beam with third point loading 100 kN cap. , hydraulic hand pump, manometer reading, sample size 15 x 15 x 60 cm, welded steel construction Dimention (l x w x h) : 100 x 50 x 100 cm Gross Weight : 110kg
  • Alat laboratorium teknik sipil Compression machine 2000 kN

    Compression machine ..

    ASTM C-39 For determining compressive strength of concrete cube 15 x 15 x 15 cm orconcrete cylinder 15 cm dia. x 30 cm height. Frame : Heavy-duty welded steel construction 30 cm (profile steel columns) 10 cm thick bottom and upper plate Hydraulic system : cast iron cylinder, For 1500 kN Cap. : hard-cromed piston, 230 mm dia maximum working pressure 50.000 kPa Overall dimension 280 mm dia. x 320 mm height.single action, gravity return. Hydraulic System : mild-steel cylinder, For 2000 kN Cap. : hard-cromed piston, 230 mm dia maximum working pressure 50.000 kPa Overall dimension 300 mm dia. x 320 mm height.single action, gravity return. Hydraulic System : mild-steel cylinder, For 3000 kN Cap. : hard-cromed piston, 250 mm dia maximum working pressure 50.000 kPa Overall dimension 330 mm dia. x 320 mm height.single action, gravity return. Hydraulic Pump : electric, 220 V-AC, 50-60 Hz, 1000 Watt, 1 Phase, single action, variable speed 6.000 ml reservoir capacity.maximum working pressure 50.000 kPa : single action, gravity return. Force Gauge : bourdon tube manometer, 280 mm dial diameter with maximum load pointer. Steel box housing. Calibrated by JNK Compressive : upper : 180 x 180 mm ball seating Platen : lower : 250 mm dia, Clearance : horizontal : 290 mm vertical : 310 mm Dimention : 760 x 320 x 1400 mm Weight : (l x w x h) approx. 500 kg Compression Machine : 1500 kN Cap. 10 kN increments Compression Machine : 2000 kN Cap. 10 kN increments Compression Machine : 3000 kN Cap. 20 kN increments
    4
  • Alat laboratorium teknik sipil laboratory concrete mixer

    laboratory concrete ..

    For mixing trial bathes of concrete for mix design, approx 70 ltr cap, 4 mixing blades welded sreel frame, 2 wheels for easy movment, electromotor 113 HP, 220 V-AC, 1 phase. Dimention (l x w x h) : 20 x 20 x 30 cm Gross weight : 30kg Also requid, but not part of this : Platform scale Squaare Pan Plastic Graduated Cylinder Trow
  • Alat laboratorium teknik sipil Core drilling machine

    Core drilling machin ..

    Core Drilling Machine cast alumunium frame,gasoline engine 55 HR, 4 cycle vertical drilling position : rubber caster, Up to 4” dia. bit 1 Set Diamon Bit 4” inner.dia 1 Pc Sample Tong 4” dia. 1 Pc Breaking Strip galvanized steel 1 Pc Spanner steel, 42 mm and 32 mm 2 Pc Dimension (l x w x h) : 97 x 57 x 150 cm Gross weight : 145kg
  • Alat laboratorium teknik sipil Sieve shaker electric

    Sieve shaker electri ..
